Marble Granite Automatic Polishing Machine

This Automatic Polishing Machine adopts foreign advanced design and automatic controlling with the demand of domestic market . it has the advantage of stable performance , high output and low failure rate .

  • Haineng
  • Fujian
  • 10 PCS Per Month
  • Information

Product Introduction

This Automatic Polishing Machine adopts foreign advanced design and automatic controlling with the demand of domestic market . it has the advantage of stable performance , high output and low failure rate . The machine select standard casting iron , steel , the brand electronic appliances , bearing and other components from Germany , Japan and Taiwan .

The controlling system of the machine adopts PLC terminal controlling , and sets the parameter by the LCD touch - screen as the man - machine interface . During running , this equipment has designed The indicator of failure and the alarm system of abrasive raw consumption . This machine is suitable for grinding and polishing large plate of marble or granite . The conveying beer advancing speed and the cross beam moving speed are controlled by transducers . The pressure of disc and the grinding width can be adjustable freely within the setting area . The machine can automatically identify the shape of plates . Every disc (grinder ) can automatically life up and down according to the identified shape and track records the grinding of plates at the same time . This Model can choose six claws flicked grinder or marble disc . The whole machine are produced by standardized production .It's performance reaches the domestic advanced level .

Marble stone polishing machine

Stone automatic polishing machine

For Marble:

Stone polishing machine

For Granite:

Marble stone polishing machine

Technical Parameters


Type

Unit

HN-12C

HN-16C

HN-18C

HN-20C

Quantity of polishing head

pcs

12

16

18

20

Useful working width

mm

600-2100

600-2100

600-2100

600-2100

Useful working thickness

mm

15-50

15-50

15-50

15-50

Transfer speed

mm/min

0-3500

0-3500

0-3500

0-3500

Water consumption

m³/h

22

25

26

28

Motor power of grinding head

kw

9/11/15

9/11/15

9/11/15

9/11/15

Total power

kw

137

181

203

225

Overall dimension(L×W×H)

mm

9600×3200×2300

11600×3200×2300

12600×3200×2300

13600×3200×2300

Gross weight

T

24

27

28

29

Processing


Stone automatic polishing machine

Loading

Stone polishing machine
